PN10/16 flanged end Y type strainer cast iron filter full size industrial filter

product description

One end is precipitation waste, impurities, usually it is installed at the inlet end of the pressure reducing valve, pressure relief valve, water level valve or other equipment, its function is the impurities in the water, to protect the normal operation of the valve and equipment, filter The water to be treated by the device enters the body from the water inlet, and the impurities in the water are deposited on the stainless steel filter screen, resulting in a pressure difference.
Features

1. Nice modeling,a pressure testing hole is preset on the body.
2. Convenient and quick use.It is possible,according to the user's requirement,to change the screwed plug on the body into a ball valve and let its outlet connected to sewage pipe,this can make it done to dredge sewage with pressure while not to remove the bonnet.
3. Filtering screens of different filtering accuracies can be provided according to the user's requirement,making the filtering screen cleaned more conveniently.
4. The fluid channel is designed scientifically and reasonably,smaller flowing resistance and greater flow.The total area of the mesh comes as 3-4times that of DN.
5. The telescopic type makes installation and removal more convenient.

Main performance parameters
PN:PN1.0Mpa,PN1.6Mpa,PN2.5Mpa
Casing test pressure:1.5Mpa,2.4Mpa,3.75Mpa
Suitable temperature:≤200ºC
Suitable media:water,steam,gas
Diameter of the filtering screen mesh:0.8~3mm


Material :

Application

Our Strainer are widely used in: independent heating systems; central heating systems; floor radiant heating systems; solar heating systems; heat pump systems; central air conditioning; heating boilers, etc.

Our products include hydraulic control valve series, balance valve series, soft seal hair series, multi-fun ction water pump control valve series, butterfly valve series, check valve series, groove valve series, fire special valve and stainless steel corrugated compensator, etc. A series of more than 1000 specifications.





y-type filter(reduced diameter)	flange thickness	flange outer circle	structure length	waterline height	waterline diameter	Height	screen diameter	filter length	filter aperture	center distance of filter	weight	length
DN50	12.5	156	201	2	102	185	48	85	2	4	4.5	205
DN65	12	175	217	2	123	210	60	95	2	4	6.5	220
DN80	14	190	247	2	134	242	68	116	2	4	8	250
DN100	14.5	209	293.5	2	157	265	82	137	2	4	10.5	298
DN125	20	240									14	315
DN150	24	280	335				113	165	2	5	19	350
DN200	24	335	405								34	410
DN250	24	405	460								58	525
DN300	24	460	520								80	605
DN350	25	520	580								98	627
DN400	27	580									126	630





company  profile



Fengbao valve factory is an entity factory with professional production experience and professional manufacturing technology. The company adheres to the business philosophy of "customer-oriented, quality-oriented, attentive service", integrates all kinds of professional advantage resources, and creates cost- effective products. The company has an excellent R & D team, dedicated to creating trustworthy products. Seek new development and create new brand.



The core team has gathered professionals with experience in product R & D, production and operation. The company attaches great importance to the growth of its employees while growing up, and has long been committed to the cohesion and improvement of their sense of responsibility, technical level and professional knowledge. The company provides development opportunities and platforms for every excellent employee, provides standardized system training and promotion mechanism, and helps employees to improve and grow in their own work field.



The company's products are mainly featured by appropriate price, excellent quality and high cost performance. Company independent research and development, production, unique production, to achieve the first-class quality, and favored by the majority of customers!



































































































































































































































































































































Q : How long is your delivery time?

A : Generally it is 15-30 days. If the goods are in stock 5 days or if the material is not at stock it requires 10 days above, it is according to quantity.

Q : Do you provide samples ? is it free or extra ?

A : Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q : What is your terms of payment ?

A : Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
