DN800 Swing Check Valve Flanged Ends PN10 Ball Float Ductile Iron

DN800 Swing Check Valve Flanged Ends PN10 Ball Float Ductile Iron
DN800 Swing Check Valve Flanged Ends PN10 Ball Float Ductile Iron

Large Image :  DN800 Swing Check Valve Flanged Ends PN10 Ball Float Ductile Iron

Product Details:
Place of Origin: CHINA
Brand Name: FB valve
Certification: ISO9001
Model Number: Ball Check Valve
Payment & Shipping Terms:
Minimum Order Quantity: 50 Pieces
Price: Negotiable
Packaging Details: plywood box
Delivery Time: 7-25 work day
Payment Terms: T/T
Supply Ability: 100 tons/ month

DN800 Swing Check Valve Flanged Ends PN10 Ball Float Ductile Iron

Description
Type: Ball Float Check Valve Port Size: 1/2"-4"
Material: Ductile Iron Certificate: ISO, SGS
Temperature Of Media: Medium Temperature Connection: Flange Ends
Model Number: H12X-16Q Working Pressure: PN10/PN16
Highlight:

DN800 swing check valve flanged

,

PN10 swing check valve flanged

,

ball float flanged swing check valve

check valve cast iron ductile iron flange ball float check valve

product description

The ductile iron ball check valve is installed on the outlet pipeline of the pump to prevent the water hammer in the pipeline from impacting the reverse of the pump and protect the safety of the pipeline when the pump is stopped. The valve is small in size, light in weight, easy to install and maintain, has a guide device, flexible closing, linear sealing, and good non-return effect, which can effectively eliminate closing noise. It is suitable for water supply and drainage, fire protection, HVAC and other related pump outlets to prevent medium backflow and water hammer damage to pumps and pipelines.



Technical conditions and materials:


1. The structure length conforms to EN 558-1, basic series 48 (DIN 3202 F6)
2. Flange connection conforms to EN 1092-2
3. Soft seal
4. Full bore
5. Applicable temperature: -20℃~120℃
6. Valve body: cast iron/ductile iron
7. Ball: EPDM package
8. Applicable size: DN50~DN800



Main Parts and Material:



Product Name
Material
Valve Body
Ductile iron, plastic spraying
Applicable temperature
≤100℃
Connection method
Flange
material
Ductile iron
Wedge Nut
Steel or Brass



Nominal diameter

50-300mm

50-300mm

50-300mm

Nominal pressure

1.0mpa

1.6mpa

2.5mpa

Shell test

1.5mpa

2.4mpa

3.75mpa

Sealing test

1.1mpa

1.76mpa

2.75mpa

Air seal test

0.6mpa

0.6mpa

0.6mpa

Applicable temperature

≤100℃

≤100℃

≤100℃

Applicable medium

water

water

water




DN800 Swing Check Valve Flanged Ends PN10 Ball Float Ductile Iron 0DN800 Swing Check Valve Flanged Ends PN10 Ball Float Ductile Iron 1DN800 Swing Check Valve Flanged Ends PN10 Ball Float Ductile Iron 2

DN800 Swing Check Valve Flanged Ends PN10 Ball Float Ductile Iron 3DN800 Swing Check Valve Flanged Ends PN10 Ball Float Ductile Iron 4


company  profile



Fengbao valve factory is an entity factory with professional production experience and professional manufacturing technology. The company adheres to the business philosophy of "customer-oriented, quality-oriented, attentive service", integrates all kinds of professional advantage resources, and creates cost- effective products. The company has an excellent R & D team, dedicated to creating trustworthy products. Seek new development and create new brand.



The core team has gathered professionals with experience in product R & D, production and operation. The company attaches great importance to the growth of its employees while growing up, and has long been committed to the cohesion and improvement of their sense of responsibility, technical level and professional knowledge. The company provides development opportunities and platforms for every excellent employee, provides standardized system training and promotion mechanism, and helps employees to improve and grow in their own work field.



The company's products are mainly featured by appropriate price, excellent quality and high cost performance. Company independent research and development, production, unique production, to achieve the first-class quality, and favored by the majority of customers!

DN800 Swing Check Valve Flanged Ends PN10 Ball Float Ductile Iron 5

DN800 Swing Check Valve Flanged Ends PN10 Ball Float Ductile Iron 6

DN800 Swing Check Valve Flanged Ends PN10 Ball Float Ductile Iron 7





DN800 Swing Check Valve Flanged Ends PN10 Ball Float Ductile Iron 8



DN800 Swing Check Valve Flanged Ends PN10 Ball Float Ductile Iron 9





























































































































































































































































































































Q: Are you a manufacturer or trading company?

A: We are a valve manufacturer and factory, and not a trading company.

Q: Do you have an agent or representative abroad?

A: We don't have an agent abroad,

please contact us to purchase valves from Fengbao Valve Co., Ltd directly.

Q: What's your product range?

A: We can produce a Gate valve, Check valve, Y strainer,

by ISO/ANSI/DIN/JIS/ EN/GOST/AS standard.

Q: Is there any stock in your factory? and how about your lead time?

A: We stock valves with normal sizes.

The lead time depends on your quantity, generally 30-40 days.

 Q: Which countries do you export to?

A: We export directly to the vast majority of countries in the world.
