Ductile Iron DN1200 Floating Check Valve PN10 Industrial Pumping Hydraulic Sewage

Certification
China Fengbao Valve Manufacturing Co., Ltd. certification
China Fengbao Valve Manufacturing Co., Ltd. certification
I'm Online Chat Now

Ductile Iron DN1200 Floating Check Valve PN10 Industrial Pumping Hydraulic Sewage

Ductile Iron DN1200 Floating Check Valve PN10 Industrial Pumping Hydraulic Sewage
Ductile Iron DN1200 Floating Check Valve PN10 Industrial Pumping Hydraulic Sewage

Large Image :  Ductile Iron DN1200 Floating Check Valve PN10 Industrial Pumping Hydraulic Sewage

Product Details:
Place of Origin: CHINA
Brand Name: FB valve
Certification: ISO9001
Model Number: Ductile Iron Check Valves
Payment & Shipping Terms:
Minimum Order Quantity: 50 Pieces
Price: Negotiable
Packaging Details: plywood box
Delivery Time: 7-25 work day
Payment Terms: T/T
Supply Ability: 100 tons/ month

Ductile Iron DN1200 Floating Check Valve PN10 Industrial Pumping Hydraulic Sewage

Description
Type:: Ductile Iron Check Valves Port Size:: DN40~DN1200
Material:: GGG50 Media:: Ewage,oil,drinking Water
Screen:: SS Wire Screen/SS Perforated Mesh End Connection:: Falnge
Power: Hydraulic Working Pressure: PN10/PN16
Highlight:

DN1200 floating check valve

,

PN10 Industrial Pumping floating check valve

,

Hydraulic sewage check valve

Ductile Iron Hydraulic Sewage Ball Check Valves for Industrial Pumping

product description

Valve in the rubber flap by steel plate, steel rod and reinforced nylon cloth to do the substrate, the
outer layer of rubber made of covering, valve disc switch life can reach 1 million times. H44X(SFCV) series rubber disc check valve adopts full flow area design, with small head loss, not easy to accumulate debris, easy maintenance and other characteristics.


BS 5153 Flexible Disc Check Valve is mainly suitable for horizontal installation of water supply and
drainage systems, can be installed at the water pump outlet, to prevent back flow and water hammer damage to the pump.
BS 5153 Flexible Disc Check Valve can also be installed in the reservoir inlet and outlet pipe bypass to prevent tank water back flow into the feed system. Check valve is generally suitable for cleaning medium, should not be used for medium containing solid particles and greater viscosity.



Main Parts and Material:





NO
NAME
MATERIAL
1
Body
Ductile Iron
2
Bonnet
Ductile Iron
3
Disk
Steel + Nylon +NBR
4
Gasket
NBR



DN
L(MM)
Flange dimensions to DIN2501(MM)

D
D1
D2


F6
5153
1
1.6
1
1.6
1
1.6
50
200
203
165
125
99
65
240
216
185
145
118
80
260
241
200
160
132
100
300
292
220
180
156
125
350
330
250
210
184
150
400
356
285
240



211
200
500
495
340
295
266
250
600
622
395
405
350
355
319
300
700
698
445
460
400
410
370
350
800
695
505
520
460
470
429
400
900
740
565
580
515
528
480
489
450
1000
830
615
640
565
585
530
548
500
1100
870
670
715
620
650
582
609
600
1300
1000
780
840
725
770
682
720
