Dn250 Ductile Iron Y Strainer Flange QT400 Water Line Sewage Pipe

Certification
China Fengbao Valve Manufacturing Co., Ltd. certification
China Fengbao Valve Manufacturing Co., Ltd. certification
I'm Online Chat Now

Dn250 Ductile Iron Y Strainer Flange QT400 Water Line Sewage Pipe

Dn250 Ductile Iron Y Strainer Flange QT400 Water Line Sewage Pipe
Dn250 Ductile Iron Y Strainer Flange QT400 Water Line Sewage Pipe Dn250 Ductile Iron Y Strainer Flange QT400 Water Line Sewage Pipe

Large Image :  Dn250 Ductile Iron Y Strainer Flange QT400 Water Line Sewage Pipe

Product Details:
Place of Origin: CHINA
Brand Name: FB valve
Certification: ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 50 Pieces
Price: Negotiable
Packaging Details: plywood box
Delivery Time: 7-25 work day
Payment Terms: T/T
Supply Ability: 100 tons/ month

Dn250 Ductile Iron Y Strainer Flange QT400 Water Line Sewage Pipe

Description
Type:: Ductile Iron Y Strainer Port Size:: DN250
Material:: QT400 Media:: Sewage,oil,drinking Water
Screen:: SS Wire Screen/SS Perforated Mesh End Connection:: Falnge
Highlight:

Dn250 Ductile Iron Y Strainer

,

QT400 Ductile Iron Y Strainer

,

Flange strainer for water line

Dn250 Sewage Outlet Flange Y Strainer QT400 For Water Pipe Line



product description

Purpose
This product is mainly set on various water supply and drainage or steam and gas pipelines and used to protect other piping or valve from getting damaged by the fragments and impurities in the system.
Features

  1. Nice modeling,a pressure testing hole is preset on the body.
  2. Convenient and quick use.It is possible,according to the user's requirement,to change the screwed plug on the body into a ball valve and let its outlet connected to sewage pipe,this can make it done to dredge sewage with pressure while not to remove the bonnet.
  3. Filtering screens of different filtering accuracies can be provided according to the user's requirement,making the filtering screen cleaned more conveniently.
  4. The fluid channel is designed scientifically and reasonably,smaller flowing resistance and greater flow.The total area of the mesh comes as 3-4times that of DN.
  5. The telescopic type makes installation and removal more convenient.



y-type filter(full bore) flange thickness flange outer circle structure lenght waterline height waterline diameter Height screen diameter filter lenght filter aperture center distance of filter
DN50 17 160 125 1.5 100 185 48 85 2 4
DN65 17 180 145 1.5 118 210 60 95 2 4
DN80 17 190 160 2 132 242 68 116 2 4
DN100 17 215 180 2 154 265 82 137 2 4
DN125   240 210 2 172
DN150   280 240 2 217   113 165 3 5
DN200 20 335 295 2 262
DN250 24     2.5 307







y-type filter(reduced diameter) flange thickness flange outer circle structure length waterline height waterline diameter Height screen diameter filter length filter aperture center distance of filter weight length
DN50 12.5 156 201 2 102 185 48 85 2 4 4.5 205
DN65 12 175 217 2 123 210 60 95 2 4 6.5 220
DN80 14 190 247 2 134 242 68 116 2 4 8 250
DN100 14.5 209 293.5 2 157 265 82 137 2 4 10.5 298
DN125 20 240                 14 315
DN150 24 280 335       113 165 2 5 19 350
DN200 24 335 405               34 410
DN250 24 405 460               58 525
DN300 24 460 520               80 605
DN350 25 520 580               98 627
DN400 27 580                 126 630
